Neo Constant Escapement Neo Constant Escapement
Neo Constant Escapement Neo Constant Escapement Neo Constant Escapement

Features

In 2013, Girard-Perregaux released the Constant Escapement L.M. to critical acclaim and won the ‘Aiguille D’Or’ at the GPHG (Grand Prix d’Horlogerie de Genève) in the same year. The model included a constant force escapement, a mechanism that delivered remarkable rate stability irrespective of the available energy. The Neo Constant Escapement is the latest evolution of the Maison’s groundbreaking approach to master energy, incorporating an array of aesthetic and technical advancements. Moreover, this new timepiece upholds Constant Girard’s original idea of showcasing the beauty of functional elements, but expressed in a contemporary way.

Download the manual

Watch

Case
Case material :
titanium
Diameter :
45 mm
Thickness :
14.8 mm
Case-back :
sapphire crystal
Dial :
no dial
Water resistance :
30 m
Strap
Strap material :
rubber
Buckle :
titanium triple-folding buckle

The Calibre GP09200

The silicium escapement spring, with an ultra-fine buckling blade at its centre, is made in a laboratory setting using a technique called ‘photolithography’. This elaborate process has allowed Girard-Perregaux to create intricately shaped components not achievable using traditional milling or stamping techniques. In this instance, Girard-Perregaux has exploited the high elasticity of silicium, the only material that allows the blade to repeatedly buckle and, in so doing, serve the balance with a constant force. The design of the Neo Constant Escapement allows the wearer to see partial views of the motion works, a theme of disclosure that extends to the escapement spring, the balance, the escape wheels, etc. In this instance, the escape wheels are supported by two independent bridges, presented in a stealthy-shade of black, each held in position with a gleaming screw. The design of the bridges was inspired by the famous bridges of the 19th century, but now executed in a modern style. Located underneath, a separate Neo bridge spans the base of the dial and supports the balance wheel. Purists will note the symmetrical design of the dial also extends to the verso view of the movement with twin barrels at the top and two Neo Bridges at the base. A linear power reserve indicator, positioned at 9 o’clock, reveals how much energy is held within the twin barrels. The movement, the Calibre GP09200, has a linear power supply of at least 7 days.

The Calibre GP09200

Movement

Calibre
COSC-certified Chronometer
Number :
GP09200
Mechanism :
hand-wound mechanical
Winding direction :
clockwise
Total Diameter :
39.50 mm (17 1/2''')
Height :
7.40 mm
Frequency :
21,600 Vib/h – (3 Hz)
Number of Parts :
266
Number of Jewels :
29
Oscillating weight :
-
Power Reserve :
min. 7 days
Functions
centre seconds, hours and minutes, power reserve
